Paramtents
Fusion Capacity 200mm Max.
Lead Time 7-15 days once order confirmed
Package Plywood case
Packging & Delivery
Min Order1 piece
Briefing
Detailed
STANDARD ACCESSORIES |
|
Main Frame
|
1 Set
|
Heating Plate
|
1 Set
|
Trimmer
|
1 Set
|
Reducers
|
1 Set
|
Tool Box | 1 Set |
Mode
|
WP200Q
|
Suitable materials
|
PE,PP, PB. PVDF
|
Range
|
63-90-110-160-200mm
|
Power supply
|
110V/220V
|
Frequency | 50HZ |
Total power | 3.65KW |
Heating plate | 1.8KW |
Planing tool | 1.1KW |
Hydraulic Unit | 0.75KW |
Max Temperature of Heating plate | 270℃ |
Pressure adjusting range | 0-6.3Mpa,Auto |
Temp.Deviation in Surface | ±5ºC |
Total Weight | 201kg |
Net weight | 181kg |
Packing Size 1 | 124*70*66cm |
Packing Size 2 | 64*47*55cm |
