Hydraulic Operated HDPE Butt Fusion Welding Machine1200/1600mm Fully
- group name
- Hydraulic Butt Fusion Machines
- Min Order
- 1 piece
- brand name
- Fusion Equipment and Plumbing Tool｜WELPING
- model
- WP1600AH
- Nearest port for product export
- Shanghai, Ningbo
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, FCA, DDU, Express Delivery
- Acceptable payment methods
- T/T, L/C, MoneyGram, Credit Card, PayPal, Westem Union
- update time
- Thu, 21 Nov 2024 19:21:08 GMT
Paramtents
Lead Time 7-15 days once order confirmed
Terms of Payment T/T, Western Union, Paypal,X Transfer
FOB Port Shanghai, Ningbo
Certificate CE
MOQ 1 Set
Business type Plastic pipe welding machines manufacturer
Packging & Delivery
-
Min Order1 piece
Briefing
The 1600mm fully hydraulic butt fusion machine is completely hydraulic which use hydraulic pressure to clamp and weld the pipes
Detailed
1200/1600mm Hydraulic Butt Fusion Welding Machine for PE Pipes
DETAILS
HDPE pipe has been used extensively in the piping applications of municipal, industrial, marine, mining, landfill, duct and agricultural industries.
Butt fusion welding is an effective, trouble free connecting method for PE, HDPE pipes. In pressurized piping applications, butt fusion welding machine can provide reliable joints, even as strong as the complete pipe.
The 1600mm butt welding machine is a mechanical butt fusion welder for joining various types of plastic pipe including HDPE,PP,PB and PVDF.
The 1600mm fully hydraulic butt welding machine features hydraulic locking and loosing,opening and closing mechanisms. With its advanced hydraulic system, this welding machine provides precise and efficient welding results.
The hydraulic butt fusion machine allow for easy access to the welding area, making it easier to set up and maintain the machine. The opening and closing mechanisms are also fully hydraulic, providing smooth and safe operation.
The machine is designed to handle large diameter pipes and provides a stable and reliable welding process. Its advanced features make it an ideal choice for welding large diameter pipes in various industries.
STANDARD ACCESSORIES |
|
|
Main Frame
|
1 Set
|
|
Heating Plate
|
1 Set
|
|
Trimmer
|
1 Set
|
|
Reducers
|
1 Set
|
Tool Box | 1 Set |
PARAMETER
|
Mode
|
WP1600AH
|
|
Suitable materials
|
PE,PP, PB. PVDF
|
|
Range
|
1200-1400-1600mm
|
|
Power supply
|
380V
|
Frequency | 50HZ |
Pressure adjusting range | 0-25Mpa |
Total power | 61.5 KW |
Heating plate | 50 KW |
Planing tool | 7.5 KW |
Hydraulic Unit | 4 KW |
Max Temperature of Heating plate | 270℃ |
Temp.Deviation in Surface | ±5ºC |
Total Weight | 5200kg |
Packing Volume | 21CBM |
PRODUCT DETAILS MAP
Basic Frame
The 1600mm fully hydraulic butt welding machine is completely hydraulic, meaning that it uses hydraulic pressure to clamp and weld the pipes. This machine has a welding pressure of up to 1600mm, which makes it ideal for welding large diameter pipes.
Open/close; lock/loose mechanisms
The machine is designed with safety in mind, with features such as an emergency stop button and safety guards to prevent accidents. The HDPE welder can control the clamps for open/close,and lock/loose.
Planning tool
The machine is made from high-quality materials, which makes it durable and long-lasting.
Controller
The machine is easy to operate, as it has a user-friendly control panel and simple controls.
Easy to operate
